69
EN
12. End point adjustment
Set the lower end point
3. +
Simultaneously press and hold the
buttons.
The roller shutters travel down.
4. +
Release the buttons, as soon as the roller
shutter reaches the desired position for
the lower end point.
The roller shutters stop and the lower
end point is stored.
i
Please ensure that the belt is not excessively
slack when reaching the lower end point.
Changing or correcting the end points
5. Move the roller shutters to the centre position and
configure the respective end point again.
i
After a period of time it may be necessary to
reconfigure the end points as the belt may
elongate during the process of operation.
