5
Physical configuration of the device.
1. LCD display (page 6).
2. Button “MENU” and its icon on the display. The button has three
functions: “MENU”, “SELECT”, “CHANGE”.
3. Button “CURSOR” and its icon on the display. The button will be
used in the menu for moving cursor.
4. Button “OFF” and its icon on the display. The button has four
functions: switch on the device, switch on backlight of LCD display,
back in menu, switch off the device.
5. Battery compartment.
The icons prompts the function of buttons to the user, thereby
facilitating the usage of the device. Further in the text the icons of
buttons are specified. The instruction to press the button with this
or that icon means clicking the relevant button on the body of the
device.
1
2
3 4 5
