36
Trunking Setup
37
Trunking Setup
While scanning,
“–”
appears for Closed mode and
“+”
appears for
Open mode under the channel storage bank’s number. When the
scanner stops on a channel,
”OPEN”
or
“CLOSED”
appears.
To set Open or Closed mode for a bank:
1. Press MAN.
2. Use S or T to select a bank.
3. Press FUNC then •/DELAY.
“Bank OPEN”
or
“Bank CLOSED”
appears.
Motorola Trunking Setup
Motorola systems can allocate as few as five frequencies or up to
several thousand groups of users in three categories:
• Type I – User groups are assigned to fleets. To scan, you must
program a fleet map into the scanner.
• Type II – The Talk Group ID contains 4 or 5 digit numbers.
• Hybrid – Combines Type I and Type II formats.
Note: For information about saving frequencies into
channels, refer to “Defining a Channel” on page 17.
Fleet Maps
For Motorola Type I and hybrid systems, you must program a fleet
map before saving Talk Group IDs.
To program a fleet map:
1. Press PROG then TRUNK.
2. Press FUNC, then press S or T to select the bank.
3. If necessary, repeatedly press MODE to select “Motorola.”
4. Press
FUNC, then press 8.
“Size Code Setting”
appears,
with Block 0 selected.
5. Enter the size code for Block 0, supplied with the Type I system
information, or try one of the following common fleet maps.
Size
Codes
BLOCKS
01234567
1
S11 S11 S11 S11 S11 S11 S11 S11
2
S4 S4 S4 S4 S4 S4 S4 S4
3
S4 S4 S4 S4 S4 S4 S12 ––
4
S12 –– S4 S4 S4 S4 S4 S4
5
S4 S4 S12 –– S4 S4 S4 S4
6
S3 S10 S4 S4 S12 –– S12 ––
7
S10 S10 S11 S4 S4 S4 S4 S4
8
S1 S1 S2 S2 S3 S3 S4 S4
9
S4 S4 SO SO SO SO SO SO
10
SO SO SO SO SO SO S4 S4
11
S4 SO SO SO SO SO SO SO
12
SO SO SO SO SO SO SO S4
13
S3 S3 S11 S4 S4 SO SO SO
14
S4 S3 S10 S4 S4 S4 S12 ––
15
S4 S4 S4 S11 S11 SO S12 ––
16
S3 S10 S10 S11 SO SO S12 ––
Note: For Motorola Type II, enter 15.
6. Press ENT. The next block appears.
7. Repeat steps 5-6 for each block. If you make a mistake, press
CLEAR and enter the correct size code.
