14
ATTACHING THE WRIST STRAP
To attach the supplied wrist strap to the top of the belt clip, thread
the strap’s small loop through the opening in the top of the clip.
Then insert the longer loop through the smaller loop and pull on
the strap until the loop is tight.
CONNECTING A MICROPHONE/
SPEAKER
You can connect an external communications headset (con-
sisting of a microphone and speaker) to the transceiver so you
can use it privately. Lift the hinged, rubber dust cover from the
MIC
and
SPK
jacks on the top of the transceiver, then insert
the plug of an optional voice activated headset with micro-
phone, or an optional communication headset, into the jacks.
19-1102RPO.fm Page 14 Friday, June 25, 1999 11:17 AM
