10
Follow these steps to install batteries in the rechargeable battery
case.
1. If the rechargeable battery case is connected to the walkie-
talkie, push the battery latch up and slide the battery case
off the walkie-talkie.
2. Using your thumb, press down on one of the arrow marks
on top of the battery case and pull it open.
3. Remove old batteries, if necessary, and install nine AA
rechargeable batteries, according to the polarity marks (+
and –) inside the battery case.
4. Press the battery case back together.
5. Charge the batteries. See “Charging Nickel-Cadmium Bat-
teries” on Page 11.
6. Slide the battery case onto the walkie-talkie.
If
BATT LOW
appears on the display, you need to recharge the
batteries.
Cautions:
• Use only replacement batteries of the required type.
