35
SPECIFICATIONS
RECEIVER
Frequency Coverage ................................ 26.965–27.405 MHz
Sensitivity ......................................... 0.7 mV for 10dB (S+N)/N
Adjacent Channel Rejection ............................................ 65 dB
Audio Distortion at 1 kHz .................................. Less than 10%
at 0.6 watts output (8 ohm)
Intermediate Frequency:
1st ................................................................... 10.695 MHz
2nd ...................................................................... 455 KHz
Current Drain:
At Standby ............................................................... 25 mA
At Maximum .......................................................... 400 mA
TRANSMITTER
Frequency Coverage ................................ 26.965–27.405 MHz
Power Input:
HI Position .............................................................. 4 watts
LOW Position ...................................................... 1.3 watts
Power Output:
HI Position ........................................................... 3.4 watts
LOW Position ......................................................... 1 watts
Modulation ................................................................... 80–95%
Spurious Output .............................................. –60 dB or better
Type of Emission ............................................................... A3E
21-1672.fm Page 35 Thursday, August 5, 1999 12:04 PM
