21
SPECIFICATIONS
Receiver
Frequency Coverage ... 26.965
–
27.405 MHz
(Supplied with Channel 14 (27.125 MHz)
crystals in the Channel A position)
Sensitivity .................. 2
µ
V for 10 dB (S+N)/N
Adjacent Channel Selectivity ................ 15 dB
Audio Output (10% THD) ................. 400 mW
Current Drain .............................. 32
–
180 mA
Transmitter
Frequency Coverage ... 26.965
–
27.405 MHz
Power Input ............ 300 mW (Into 50
Ω
Load)
Power Output at No Modulation ....... 150 mW
(Into 50
Ω
Load)
Current Drain at No Modulation ......... 100 mA
Type of Modulation .................................... A3
AMC Range at 50 to 100%
Modulation ............................................ 35 dB
Spurious Emission .............................. –67 dB
Frequency Tolerance .......................... 0.005%
Telescoping Antenna Impedance ............ 50
Ω
Antenna Length (Maximum) .............. 28
3
/
8
In.
(721 mm)
Dimensions (HWD) .......... 8
1
/
4
×
2
13
/
16
×
1
7
/
8
In.
(210
×
71
×
48 mm)
Weight .................................................. 8.8 oz
(255 g)
Specifications are typical; individual units
might vary. Specifications are subject to
change and improvement without notice.
21-1615.fm Page 21 Thursday, August 5, 1999 11:07 AM
