2.3.3 Display Modes
Live Display Mode Loops:
The Display mode loop alternates between Coax and IFD (Intermittent Fault Detection) mode.
Line Displays active test port.
IFD Displays IFD waveform.
Recalled Display Mode Loops:
When a waveform has been recalled from memory, the Mode control will cycle through display modes involving the
coaxial test port and the recalled waveform. The loop described below applies to the test port.
Line & Stored Displays Live and Stored waveforms simultaneously.
Line-Stored Displays difference between Live and Stored waveform.
Stored Displays Stored waveform only
Line* Displays Coax (active test port) waveform
* To exit the recalled waveform loop, enter the Live mode and wait five seconds.
