Model Setup Detailed options：
Model name
：
Enter your model name here.
Model image：You can select a picture file as the model logo in the BMP folder
of the SD card. Pictures can be viewed using the SD card manager.
Timer1-3：
Up to 3 fully programmable timers that can count up or down.
Timer always on once throttle is not all the way down
Timer on when throttle is not all the way down
Timer speed proportional the throttle
THR 100% Timer 1 second intervals, THR 50% Timer 2
second interval
Setting the timer to a value above 00:00 puts it into count
down mode
Name
：
Name the timer
Persistent ： Timer retains its value when the Tx is powered of and on or the
model is changed
Minute call ：Required SD card with sound pack installed. At each minute the
value spoken.
Countdown：-Countdown broadcast, default 10s (10 seconds)
Voice broadcast countdown
Extended limits
：
Expand the limit. After checking, set the channel rudder limit
to ± 125% (default maximum ± 100%).
