Radleys Reactor-Ready - Reactor-Ready Component Guide

Reactor-Ready - Lab Reactor
6. Component Guide
Page 5
1
3
5
6
7
8
8
9
12
13
14
16
19
18
15
17
4
10
11
Reactor-Ready Core System
1. Adjustable Feet
2. HDPE Drip Tray
3. Aluminium Base
4. Support Rod Bosses
5. Support Rods
6. Inlet Manifold
7. Outlet Manifold
8. Safety Stop Collars
9. Vessel Support Clamp
10. T-Beam Support Brace
11. Stirrer Support I-Brace
(with sliding boss)
12. Quick Release Insulated hoses
13. Rodaviss hose sealing caps
14. Vessel Support Collars
15. Glass Lid with Sealing Caps
16. PTFE Stirrer Guide
17. Locking Rod for Support Rod Bosses
18. Stirrer Drive Coupling
19. O-ring Seal and PTFE
Support Collar
2
A
E
B
D
C
Reaction Vessel kits
A. Glass Reaction Vessel with PTFE Stopcock
B. PTFE Anchor Stirrer
C. Sidearm Couplings (Connecting cap and connecting clip)
D. Pt100 PTFE Temperature Probe
E. PTFE Temperature Probe Adapter
