RADWAG PS 1200.R2

- 7 -
1. TECHNICAL DATA
Balance XA series:
XA 52.R2 XA 82/220.R2
Max capacity 52 g 82/220 g
Min capacity 1 mg 1 mg
Readability 0,01 mg 0,01/0,1 mg
Tare range
-52 g -220 g
Repeatability
0,02 mg 0,02 /0.08 mg
Linearity
± 0,06 mg ± 0,06/0,2 mg
Eccentric load deviation
0,06mg 0,2mg
Pan size
Ø85mm
Dimensions:
