Rain Bird T-Bird T-22 User Manual

4
Set left trip point.
4
AA
Be sure water is turned OFF before setting
FIXED left trip point.
BB
Pull up turret and turn it to the left trip point. Caution:
If rotor does not turn easily to the left, first turn it right
to right trip point. Then turn left to left trip point.
CC
Left trip point is marked by screw next to nozzle re-
tainer. To change left trip point, unscrew cap and pull
out assembly. Rotate internals to realign left trip point
to desired position and reinstall in this position. Screw
on cap. For bottom inlet installations, rotate case on
riser to desired position.

Rain Bird T-Bird T-22 Specifications

General

Brand	Rain Bird
Model	T-Bird T-22
Category	Irrigation System
Language	English
