2.0 Model Pro Max Remote Control System (Rain Master Only)
The Pro Max receiver is designed to connect directly to any Rain Master controller by plugging
the 9-pin connector from the Pro Max receiver into the front panel remote control jack found ON
Rain Master controllers.
Figure 2: Complete Pro Max System
Pro Max Parts List
Part No. Ref. Description
PM-XMTR 1 Pro Max Remote radio transmitter
PM-RCVR 2 Pro Max Remote receiver
PM-SER99 3 36” remote cable
500055 4 Pro Max User’s manual
PM-CASE 5 Pro Max carrying case
PM-ANT-XMTR 6 Antenna, BNC
PM-ANT-RCVR 7 Antenna, hinged, BNC
