Rain Master Irrigation Systems Pro Max User’s Manual
3.0 Model Pro Max-UA Remote Control System (Universal)
The Pro Max-UA Universal Adapter Model offers the capability to connect to virtually any
controller, regardless of manufacturer. This system consists of:
Figure 6: Complete Pro Max-UA System
Pro Max-UA Parts List
Part No. Ref. Description
PM-XMTR 1 Pro Max Remote radio transmitter
PM-RCVR 2 Pro Max Remote receiver
PM-SER99 3 36” remote cable
PM-UADAPT 4 Universal adapter
32 PC 5 30” permanent connector
500055 6 Pro Max User Manual
PM-CASE 7 Pro Max carrying case
PM-ANT-XMTR 8 Antenna, BNC
PM-ANT-RCVR 9 Antenna, hinged, BNC
Page 15
