Wiring List for PROMAX-UA
Station Base Color 1
st
Stripe
Color
2
nd
Stripe
Color
Cable
1 Black Large
2 White Large
3 Red Large
4 Green Large
5 Orange Large
6 Blue Large
7 White Black Large
8 Red Black Large
9 Green Black Large
10 Orange Black Large
11 Blue Black Large
12 Black White Large
13 Blue Red Large
14 Red Green Large
15 Orange Green Large
16 Black White Red Large
17 White Black Red Large
18 Red Black White Large
19 Green Black White Large
20 Orange Black White Large
21 Blue Black White Large
22 Black Red Green Large
23 White Red Green Large
24 Red Black Green Large
25 Black Small
26 White Small
27 Red Small
28 Green Small
29 Brown Small
30 Blue Small
31 Orange Small
32 Yellow Small
MV/P Green White Large
COMMON Orange Red (Standard) Large
COMMON* Red White Large
24 VAC Blue White Large
*Some cables may use this color scheme for common
