Operational Specifications continued from page 5
Data Chart for ION-X 100 T Resin
Data Chart for ION-X 34 D Resin
6
Model
Tank Size
(inches)
Resin*
(cu. ft.)
Service
Flow
(gpm)
Drain
Flow
(gpm)
psi Drop
High
Salting
Medium
Salting
Low
Salting
TC 250 T 13 x 54 2.5 11.4 3.0 12.0
76,200 @
37.5 lbs.
65,400 @
25.0 lbs.
33,800 @
7.5 lbs.
TC 250 CT 13 x 54 2.5 11.2 3.0 13.0
76,200 @
37.5 lbs.
65,400 @
25.0 lbs.
33,800 @
7.5 lbs.
TC 400 T 14 x 65 4.0 10.8 4.0 12.0
122,000 @
60.0 lbs.
104,700 @
40.0 lbs.
54,100 @
12.0 lbs.
TC 400 CT 14 x 65 4.0 10.7 4.0 12.0
122,000 @
60.0 lbs.
104,700 @
40.0 lbs.
54,100 @
12.0 lbs.
TC-CAB 60 T 10 x 35 0.6 10 2.0 9.0
11,900 @
9.0 lbs.
10,000 @
6.0 lbs.
4,800 @
1.8 lbs.
TC-CAB 60 CT 10 x 35 0.6 10 2.0 9.0
11,900 @
9.0 lbs.
10,000 @
6.0 lbs.
4,800 @
1.8 lbs.
TC-CAB 60SS T 10 x 18 0.6 10 2.0 9.0
11,900 @
9.0 lbs.
10,000 @
6.0 lbs.
4,800 @
1.8 lbs.
TC-CAB 60SS CT 10 x 18 0.6 10 2.0 9.0
11,900 @
9.0 lbs.
10,000 @
6.0 lbs.
4,800 @
1.8 lbs.
TC-CAB 100 T 10 x 35 1.0 10.0 2.0 10.0
30,500 @
15.0 lbs.
26,100 @
10.0 lbs.
13,500 @
3.0 lbs.
TC-CAB 100 CT 10 x 35 1.0 10.0 2.0 11.0
30,500 @
15.0 lbs.
26,100 @
10.0 lbs.
13,500 @
3.0 lbs.
Model
Tank Size
(inches)
Resin*
(cu. ft.)
Service
Flow
(gpm)
Drain
Flow
(gpm)
psi Drop
High
Salting
Medium
Salting
Low
Salting
TC 50 D 8 x 44 0.5 10.0 1.5 14.0
17,400 @
7.5 lbs.
14,200 @
5.0 lbs.
6,600 @
1.5 lbs.
TC 50 CD 8 x 44 0.5 7.8 1.5 9.0
17,400 @
7.5 lbs.
14,200@
5.0 lbs.
6,600 @
1.5 lbs.
TC 60SS D 10 x 18 0.6 10 2.0 9.0
19,000 @
9.0 lbs.
15,500@
6.0 lbs.
7200 @
1.8 lbs.
TC 60SS CD 10 x 18 0.6 10 2.0 9.0
19,000 @
9.0 lbs.
15,500 @
6.0 lbs.
7,200 @
1.8 lbs.
TC 60S D 10 x 35 0.6 10 2.0 9.0
19,000 @
9.0 lbs.
15,500@
6.0 lbs.
7,200 @
1.8 lbs.
TC 60S CD 10 x 35 0.6 10 2.0 9.0
19,000 @
9.0 lbs.
15,500 @
6.0 lbs.
7,200@
1.8 lbs.
TC 75 D 8 x 44 0.75 8.8 1.5 15.0
26,100 @
11.2 lbs.
21,300 @
7.5 lbs.
9,900 @
2.25 lbs.
TC 75 CD 8 x 44 0.75 9.2 1.5 14.0
26,100 @
11.2 lbs.
21,300 @
7.5 lbs.
9,900 @
2.25 lbs.
TC 100 D 10 x 44 1.0 10.0 2.0 10.0
34,500 @
15.0 lbs.
30,500 @
10.0 lbs.
14,200 @
3.0 lbs.
TC 100 CD 10 x 44 1.0 9.4 2.0 9.0
34,500 @
15.0 lbs.
30,500 @
10.0 lbs.
14,200 @
3.0 lbs.
TC 100S D 10 x 35 1.0 10.0 2.0 10.0
34,500 @
15.0 lbs.
30,500 @
10.0 lbs.
14,200 @
3.0 lbs.
TC 100S CD 10 x 35 1.0 10.0 2.0 10.0
34,500 @
15.0 lbs.
30,500 @
10.0 lbs.
14,200 @
3.0 lbs.
TC 150 D 10 x 54 1.5 10.2 2.0 12.0
51,800 @
22.5 lbs.
45,800 @
15.0 lbs.
21,400 @
4.5 lbs.
TC 150 CD 10 x 54 1.5 7.8 2.0 8.0
51,800 @
22.5 lbs.
45,800 @
15.0 lbs.
21,400 @
4.5 lbs.
TC-CAB 60SS D 10 x 18 0.6 9.5 2.0 9.0
19,000 @
9.0 lbs.
15,500 @
6.0 lbs.
7,200 @
1.8 lbs.
TC-CAB 60SS CD 10 x 18 0.6 9.5 2.0 9.0
19,000 @
9.0 lbs.
15,500 @
6.0 lbs.
7,200 @
1.8 lbs.
TC-CAB 60 D 10 x 35 0.6 9.5 2.0 9.0
19,000 @
9.0 lbs.
15,500 @
6.0 lbs.
7,200 @
1.8 lbs.
TC-CAB 60 CD 10 x 35 0.6 9.5 2.0 9.0
19,000@
9.0 lbs.
15,500 @
6.0 lbs.
7,200 @
1.8 lbs.
TC-CAB 100 D 10 x 35 1.0 10.0 2.0 10.0
34,500 @
15.0 lbs.
30,500 @
10.0 lbs.
14,200 @
3.0 lbs.
TC-CAB 100 CD 10 x 35 1.0 10.0 2.0 10.0
34,500 @
15.0 lbs.
30,500 @
10.0 lbs.
14,200 @
3.0 lbs.
* Cation Exchange Media
Higher or lower pressure will affect the
efficiency of the system.
If the iron content of the water to be soft-
ened is zero, and the hardness level is
less than 20 gpg, we suggest you choose
the low salt setting for the most efficient
operation. Please go to page 13 for the
instruction of how to set the pounds of
salt.
* Cation Exchange Media
Higher or lower pressure will affect the
efficiency of the system.
If the iron content of the water to be soft-
ened is zero, and the hardness level is
less than 20 gpg, we suggest you choose
the low salt setting for the most efficient
operation. Please go to page 13 for the
instruction of how to set the pounds of
salt.
