Pro2-Series 3D Printer
/ Quick Start Guide
H. Dual-Extruder Print - Start First Print (continued)
Please use the feeler gauge to check the
distance between nozzle and printing platform.
The optimal distance between is 0.2mm.
The best condition of this is that you can feel a
little friction when you slide the feeler gauge
into the gap.
5
0.2mm
Feeler Gage
The distance between the nozzle and the
printing platform can be adjusted by turning the
thumb screw on the left-front corner of the
Z-plate, the higher the screw stands, the further
the distance between the nozzle will be from the
printing platform.
Home the Z axis after each adjustment.
6
Closer Further
01 02
03 04 05 06
07 08 09 10
11 12 13 14
15 16 17 18
19 20 21 22
23 26
Once the left nozzle moves down, the right
nozzle will go up.
4
24 25
