Raisecom RC1201-2GE16E1T1 User Manual

Raisecom
RC1201-2GE16E1T1 Product Description
6 Installation
Raisecom Technology Co., Ltd.
79
6.5.4 Checking cables
After installation is complete, check the RC1201-2GE16E1T1 as listed in Table 6-7.
Table 6-7 Checking cables
Item
Requirement
Power wire
and earth
wire

The connection is correct and reliable. Power cable inside the rack,
ground wire and signal line are laid separately; the distance among
power cable outside the rack, ground wire and signal line meet the
design requirements, generally greater than 3 cm.

Wrap wire nose handle and bare wire required with heat-shrinkable
tubing or insulating tape. There is no bare copper wire at wire nose and
connection terminal, flat washer and spring washer are installed
correctly.

Bind the wire straightly and neatly, and all the wire clips should be
aligned towards the same direction.
Cable

The rack alignment is correct.

No damage, breakage, and middle connector.

The plug is clean and without damage; plugs made on site should be
proper and plugs connection is correct and reliable.

The line routing is in line with the engineering design manual, easy to
maintenance and capacity expansion.

Optical fibers, optical interfaces and flange plates should be connected
reliably.

Laying tail fiber outside the cabinet shall take protective measures, such
as adding bellows or channels, etc.
6.5.5 Power-on check
Conduct power-on check, as listed in Table 6-8.
Table 6-8 Power-on check
Item
Requirement
DC and AC
power

Check that the positive and negative polarities of DC power are
correctly connected. Use a multi-meter to test DC power, ensuring that
the DC power voltage is between -36 V to -72 V or +18 V to +36 V.

Use a multi-meter to test AC power, ensuring that the AC power voltage
is between 176 V to 264 V.

The power insurance capacity must allow the normal operation of the
RC1201-2GE16E1T1 under the maximum power consumption.
Optical power

Use optical power meter to measure the SFP module and its optical
power is P1. Compare P1 with SFP indicator to confirm that SFP optical
module is working normally.

Connect optical fiber at the ODF side to optical power meter, and the
measured optical power is P2. If the difference between P2 and P1 is
smaller than 1 dB, the optical fiber is connected normally.
