RAK7249 User Manual V1.3
 LoRa concentrator
Standard version with 8 channel Gateway and also support Max.16 channel
Gateway.
Tx Power is up to 27dBm and Rx sensitivity is down to -142dBm.
 4G Cellular
Quectel EG95 for CAT4 cellular network.
 L70 GPS Module
 Power-over-Ethernet (PoE)
100M base-T Ethernet with IEEE802.3af/at standard Power-over-Ethernet.
2.2 Enclosure
 IP67 waterproof white color.
 Interface: 5 x N-Type connectors for Antenna,1 PoE port and 1 reserve port.
 Weight (with cable): approximately 70.54oz (2kg).
 Dimensions: 220mm x 220mm x 104mm.
 Wall thickness: 2mm.
 Support up to 70~100 mm diameter pole mount.
2.3
Backup Battery
 12V lithium battery, capacity is 5000mAH for more than 5 hours lifetime under
typical operation.
 Battery powered real time clock.
 Battery Within 140 x 70 x 30mm.
 DC 5.5 x 2.1 circular joint with two interfaces, one male and one female.
2.4
Accessories
 Mounting Kit
 PoE Injector
 WiFI Antenna
 GPS Antenna
 LoRa Antenna
 LTE Antenna
