RAK7249 User Manual V1.3
5 Product Specifications
5.1 Main Specifications
Feature
Specifications
Computing
 MT7628, DDR2RAM 128MB
WIFI Feature
 Frequency: 2.400-2.4835GHz(802.11b/g/n)

RX Sensitivity: -95dBm (Min), TX Power: 20dBm (Max)
 Operation Channels: 2.4GHz: 1-13
LoRa Feature
 SX1301 Mini PCIe card (connects maximum of two),
8Channels (Optional: 16channels)
 RX Sensitivity: -142dBm (Min), TX Power: 27dBm (Max)
 Frequency: EU433, CN470, EU868, US915
AS920, AS923, AU915, KR920, IN865
Cellular Feature
 With EG95: LTE CAT 4

Cellular Variant for Europe

LTE FDD: B1/B3/B7/B8/B20/B28A
 WCDMA: B1/B8
 GSM: 900/1800MHz
 Cellular Variant for North America

LTE FDD: B2/B4/B5/B12/B13

WCDMA: B2/B4/B5
Power Supply
 PoE(IEEE 802.3af/at-Compliant), 42~57VDC
Power Consumption
 12W (typical)
ETH

RJ45(10/100M)
Antenna

5 N-Type connectors
Ingress Protection

IP67
Enclosure Material
 Aluminum
Weight
 Approximately 111.11oz (3.15kg)
Dimension
 220mm x 220mm x 104mm
Operating Temp.

-30˚C to 65 ˚C
Installation method

Pole or Wall mounting
Table 2 | Main Specifications
