272 STARTING AND OPERATING
2. Remote Socket: The remote socket (which
will be located on the bumper assembly)
allows the remote control to be attached to
the control pack to allow the winch to
function.
3. Winch Drum With Integral Brake: The winch
drum allows the rope to be stored on the
winch and transmits force to the rope. The
winch is equipped with an integral brake
that will stop rotation of the winch drum if
the winch motor is stopped.
4. Synthetic Rope: The synthetic rope allows
the winch to be connected to an anchor to
provide a pulling force. This synthetic rope is
highly flexible, lightweight, and it floats.
5. Clutch Lever: The clutch lever allows the
winch drum to be disconnected from the
winch motor to allow the rope to be pulled
from the winch by hand.
6. Remote Control: The remote control
provides the interface between the winch
operator and the winch. The remote control
provides the ability to power the winch in,
out, and stop the winch. To operate the
winch, the toggle switch is pressed down to
power the winch in and up to power the
winch out. The winch will stop if the switch
is left in the neutral (center) position.
Fairlead: The hawse fairlead acts as a guide for
the synthetic rope and minimizes damage to the
rope.
WINCH ACCESSORIES
The following accessories are necessary to
attach the winch to anchors, change direction of
pull, and for safe winching.
Gloves: It is extremely important to
wear protective gloves while
operating the winch or handling the
winch rope. Avoid loose fitting clothes
or anything that could become entangled in the
rope and other moving parts.
Snatch/Block Pulley: Used properly,
the multi-purpose snatch block allows
you to (1) increase the winch's pulling
power; and (2) change your pulling direction
without damaging the winch rope. Proper use of
the snatch block is covered in "Before You Pull."
Clevis/D-Shackles: The D-Shackle is
a safe means of connecting the
looped ends of cables, straps and
snatch blocks. The shackle's pin is
threaded to allow easy removal.
Tree Trunk Protector: Typically made
of tough, high-quality nylon, it
provides the operator an attachment
point for the winch rope to a wide
variety of anchor points and objects, as well as
protect living trees.
Abrasion Sleeve: The abrasion sleeve is
provided with the synthetic rope and must be
used with the synthetic rope at all times to
protect the rope from potential abrasion wear.
The sleeve has a loose fit so it can easily be
positioned along the synthetic rope to protect
from rough surfaces and sharp corners.
CAUTION!
If not installed, the hook strap must be
placed on the hook.
