364 IN CASE OF EMERGENCY
F100 – 10 Amp Red Upfitters Box Feed– If Equipped
F101 – 20 Amp Yellow Rear Heated Seat Right — If Equipped
F102 – 20 Amp Yellow Rear Heated Seat Left / Run RLY #3 Coil — If Equipped
F103 – 10 Amp Red HeadLamp AFLS — If Equipped
F104 – 20 Amp Yellow UCI Port / USB Rear
Cavity Cartridge Fuse Micro Fuse Description
CAUTION!
When installing the power distribution center cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may
allow water to get into the power distribution center and possibly result in an electrical system failure.
When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indi-
cated may result in a dangerous electrical system overload. If a properly rated fuse continues to blow, it indicates a problem in the circuit that must
be corrected.
20_DJD2_OM_EN_USC_t.book Page 364
