RAMSET RAM 1000 - Entrapment and Safety Protection

12
RAMSET
www.ramsetinc.com
RAM 100 • 1000 • 5500
In order to prevent serious injury, bodily harm or death from a moving gate:
- Entrapment protection devices must be installed to cover any and all entrapment danger areas and
locations during a gates opening and closing cycles.
Since every installation is different, it is up to a qualified and trained technician to determine:
- All Possible Entrapment areas & locations
- The amount and type of entrapment protection devices that are needed.
Approved anti-entrapment devices:
- Miller’s Edge “PrimeGaurd
- Miller’s Edge “ReflectiGaurd”
- Miller’s Edge “Wireless Edge Link”
- Miller’s Edge “The Solution”
- EMX ”IRB-MON”
WARNING
ENTRAPMENT AND SAFETY PROTECTION
1 - TRAILING EDGE - ENTRAPMENT
2 - CENTER POST - ENTRAPMENT
3 - LEADING EDGE - SAFETY
4 - CATCH - SAFETY
5 - BACK PLANE ZONE - ENTRAPMENT
6 - INTERIOR ZONE - SAFETY
7 - EXTERIOR ZONE - SAFETY
