RAM 100 • 1000 • 5500
ITEM PART # PART DESCRIPTION RAM 100 RAM 1000 RAM 5500-3/4 RAM 5500-1
1 800-00-00 Chassis - R100 1
2 800-00-01 Chassis - R1000/R5500s 1 1 1
3 800-02-03 Gear Reducer - Size 43, Ratio 30:1 (C-Face) 1
4 800-02-06 Gear Reducer - Size 60, Ratio 30:1 (C-Face) 1 1 1
5 800-04-00 Motor, C-Face - 120 VAC 1/2 HP 1 1
6 800-04-01 Motor, C-Face - 120 VAC 3/4HP 1
7 800-04-02 Motor, C-Face - 120 VAC 1Hp 1
8 800-06-08 Sprocket - 41B12 x 1/2" 1
9 800-06-09 Sprocket - 41B15 x 3/4" 1 1 1
10 800-14-20 Cover, Metal Control Board 1
11 800-20-00 Limit Switch - R100 2
12 800-20-01 Limit Switch - R1000/R5500s 2 2 2
13 800-20-20 Switch, Foot Pedal - R100/R1000/R5500s 1 1 1 1
14 800-22-02 Spring - 1/2" x 2" 1 1 1 1
15 800-22-04 Spring - 1/4" x 1/2" 2 2 2 2
16 800-24-20 Fork, Pedal Release - 3 3/4" x 2 3/4" 1
17 800-24-21 Pedal Release Fork - 3 7/8" x 2 13/16" 1 1 1
18 800-52-21 Chain, Limit - #41 x 22" (22 Links) 1 1 1
19 800-54-75 Bracket, Spring Loaded - 6 1/2" x 1 1/4" 1
20 800-54-76 Bracket, Spring Loaded - 6 3/4" x 7/8" 1 1 1
21 800-60-01 Transformer, 115/230VAC TO 20VAC - 20VA (1A) 1 1 1 1
22 800-60-10 Switch, Rocker 1 1 1
23 800-63-00 Control Board - Intelligate - Domestic UL 1 1 1 1
24 800-64-00 Edge Connector - 20 Pin 1 1 1 1
25 800-64-50 Radio Receiver Terminal 1 1 1 1
26 800-66-00 Lexan Control Board Cover- 9 1/4" x 15 1/4" 1 1 1
27 800-68-01 Instruction Manual - R100/R1000/R5500s 1 1 1 1
28 800-70-21 Horn Alarm Buzzer - 120dB 1 1 1 1
29 800-70-52 Plate, Bearing - 2 1/4" x 2 3/8" 1 1 1
30 800-70-75 Shelf, Accessories 1 1 1
31 800-70-98 Warning Sign For Gates - Slide/Swing 2 2 2 2
32 800-75-20 CLUTCH RELEASE ASSEMBLY - R100 1
800-06-11 Sprocket, Clutch Release - 41B21H - R100 1
800-22-00 Spring - 1 1/4" x 1 1/4" (6 turns) 1
800-24-00 4-Pin Disc - R100 1
800-40-55 Washer, Flat - ID 1 1/16" : OD 2" 2
800-58-20 Arbor, Clutch Release - R100 1
800-70-86 Snap Ring, External - 1 1/2" 1
33 800-75-21 CLUTCH RELEASE ASSEMBLY - R1000/R5500S 1 1 1
800-06-12 Sprocket, Dual Clutch Release - 41B25/27 - R1000/R5500s 1 1 1
800-22-06 Spring - 1 1/4" x 1" (3 1/4 turns) 1 1 1
800-24-01 4-Pin Disc - R1000/R5500s 1 1 1
800-40-56 Washer, Flat - ID 1 1/16" : OD 2" : Thickness .090" 1 1 1
800-58-21 Arbor, Clutch Release - 1" 1 1 1
800-70-86 Snap Ring, External - 1 1/2" 1 1 1
34 800-75-30 IDLER WHEEL ASSEMBLY - R100 1
800-36-52 Bolt, Hex Head - 5/8" - 11 x 3 1/2" 1
800-38-18 Nut, Hex Head - 5/8" 1
800-73-70 Idler Wheel, UHMW - 2 1/2" x 1 1/4" - I.D. 5/8" 1
BILL OF MATERIALS
