RAMSET RAM 1000 - UL Gate Classification; Recommended Electrical Connection; Recommended Wire Gauge

5
RAM 100 • 1000 • 5500
RAMSET
www.ramsetinc.com
MODEL HP VOLTAGE RUN START
R100/R1000 1/2 115VAC 4.5 5.0
R5500-3/4 3/4 115VAC 8.5 9.0
R5500-1 1 115VAC 9.4 9.9
12GA 10GA 8GA 6GA
up to 225' 226-370' 371-550' 551-925'
up to 115' 116-195' 196-290' 291-495'
N/A up to 175' 176-265' 266-445'
Class I Residential Vehicular Gate Operator (3.19)
A vehicular gate operator (or system) intended for use in garages or parking areas associated with
a residence of one-to four single families.
Class II Commercial/General Access Vehicular Gate Operator (3.4)
A vehicular gate operator (or system) intended for use in a commercial location or building such
as a multi-family housing unit (five or more single family units), hotel, garages, retail store or other
buildings accessible by or servicing the general public.
Class III Industrial/Limited Access Vehicular Gate Operator(3.11)
A vehicular gate operator (or system) intended for use in an industrial location or building such as a
factory or loading dock area or other locations not accessible by or intended to service the general
public.
Class IV Restricted Access Vehicular Gate Operator (3.20)
A vehicular gate operator (or system) intended for use in a guarded industrial location or building
such as an airport security area or other restricted access locations not servicing the general public,
in which unauthorized access is prevented via supervision by security personnel.
A 3 wire, 115VAC electrical circuit with a 15 amps independent circuit breaker for single operator
and a 20 amps for Primary/Secondary. Ideally, the electrical conduits should exit the concrete
under the operator. Low voltage control wires must be run in a separate conduit to the operator.
NOTE: ALWAYS CONSULT AND FOLLOW ALL LOCAL BUILDING AND ELECTRICAL CODES
PRIOR TO INSTALLATION.
UL GATE CLASSIFICATION
RECOMMENDED ELECTRICAL CONNECTION
RECOMMENDED WIRE GAUGE
