Fire Pont Technical Data
Model Numbers: W2-BST-GSM-U, W2-BST-GSM-N, W2-BST-STD-U, W2-BST-STD-N
Device Parameters
Dimensions (mm) HxWxD 235 x 161 x 128 (excl. antenna 81mm and USB 15mm)
Weight 1.5kg
Operating Temperature: -25°C to +70°C
Humidity: Relative Humidity >95% (25°C to 55°C)
Supply Parameters
Operating Voltage Range: 4.4-6.4V from internal battery
Power: 620μW average
Current Consumption: 120μA average
Battery type: Alkaline primary cells, 23Ah
Pack life: > 4 years
Estimated life (eld usage): > 5 years
RF Parameters
Operating frequency: 868.3MHz
Transmit power: 25mW max
Duty Cycle: <1%
Encryption: none
Channel spacing: single channel
Compatible with: other WES+ units
Protocol: proprietary
Transmit Band (Tx) Receive Band Power
E-GSM 900 880 to 915 MHz 925 to 960 MHz 2 Watts EGSM 900 radio section
DCS 1800 1710 to 1785 MHz 1805 to 1680 MHz 1 Watt GSM1800 radio section
Base Station Technical Data
