DST-64T / DST642D Wheel Balancers 20 P/N 5900192 — Rev. F — March 2021
Anchoring the Balancer
The Balancer has four holes in the Base for Anchor Bolts, which hold the Balancer in place while in
use.
Important: You are
required
to bolt your Balancer into place, as movement during a Wheel
Balance can result in inaccurate readings.
To anchor the Balancer:
Move the Balancer to the desired location.
Remember that you need to allow some space around the Balancer. Refer to Finding a
Location for additional information.
Using the holes in the base as guides, drill the holes for the Anchor Bolts.
Go in straight; do not let the drill wobble. Use a carbide bit (conforming to ANSI B212.15).
The diameter of the drill bit must be the same as the diameter of the Anchor Bolt. So if you are
using an M10 diameter Anchor Bolt, for example, use an M10 diameter drill bit.
Vacuum each hole clean.
BendPak recommends using a vacuum to get the hole very clean.
Do
not
ream the hole. Do
not
make the hole any wider than the drill bit made it.
Make sure the Washer and Nut are in place, then insert the Anchor Bolt into the hole.
The Expansion Sleeve of the Anchor Bolt may prevent the Anchor Bolt from passing through the
hole in the Base Plate; this is normal.
