DST-64T / DST642D Wheel Balancers 58 P/N 5900192 — Rev. F — March 2021
158 Type B Reed Nut, M6
159 Cross Recess Brazier Head Screw, M6 by 20
160 Socket Hexagon Socket Head Screw with Flange Face
DST-64T Hood Mount
Part # Number Description
204 HHB, M8 by 20
205 Washer, 8 mm Flat
5327091 206 Motor Belt
207 Nut, M10
208 Pizo Sensor Pad
5327141 209 Vertical Pizo Sensor
5327139 210 Pizo Vertical Shaft
5327140 211 Pizo Horizontal Shaft
5328009 212 Weight Indicator Light
213 Chuck Guard
214 SSS ST 4.8 by 16
