Ranger DST-64T User Manual

DST-64T / DST642D Wheel Balancers 59 P/N 5900192 — Rev. F — March 2021
5328010 215 Thread Shaft Plastic Cover
5328011 216 Pizo Wires
225 Encoder Board
217 SHCS, M4 by 12
218 Tooth
219 SHCS, M6 by 20
220 Bearing Cover
221 Snap ring, 30 mm
222 Bearing 6006
222-1 Bearing 6005
223 Snap Ring, 25 mm
5327143 224 Spindle with Position Board
5327686 226 Encoder Bracket
227 Deformation of Beams
5328012 228 Hood Mounting Assy Bracket
5327169 229 Hood Switch
5327572 229-1 Short Hood Switch Wires
5328013 229-2 Hood Switch Wire 1
230 Hexagon Socket Set Screw with Flat Point, M8 by 12
5327171 231 Hood Cam
5327168 232 Hood Spring
5327180 233 Adjustable Eye Bolt, M8 by 1.25
234 Washer, 8 mm
5327170 235 Hood Cam Stop
236 Nut, M8
237 SHCS, M8 by 25
5327167 238 Hood Shaft Bushing
5327166 239 Hood Rotating Shaft
240 Snap Ring, 38 mm
241 SHCS, M12 by 40
242 HHB, M8 by 30
5327164 243 Hood Mounting Assembly Upper Cover
244 SHCS, M8 by 20
245 Washer, 8 mm Flat
5328014 246 Hood Mounting Assembly
247 Threaded Shaft/Spindle with Position Board
248 Washer, 8 mm Split Lock
249 Sensor Flat Mat
