Ranger DST30P - Page 50

DST30P Wheel Balancer 50 P/N 5900163 — Rev. C1 — March 2020
BendPak # ID Number Description
5327139 119 Pizo Vertical Shaft
5327140 120 Pizo Horizontal Shaft
5327141 121 Vertical Pizo Sensor
124 Spindle Bushing Weldment
125 Encoder Board
5327686 125-1 Encoder Board Bracket
125-2 Wires, encode sensor to computer board
5327091 126 Motor Belt
138 HHB M8 by 20
139 Washer, 8 mm flat
140 SHCS, M8 by 20
141 Washer, 8 mm spring
142 Washer, 8 mm wide flat
143 Locknut, M10
144 Pizo Sensor Pad
145 Self Taping Screw, M4.8 by 16
146 Deformation of Beams
147 SHCS, M8 by 20
148 Tootch, 32T
149 SHCS, M8 by 20
150 Bearing Cover
151 Seeger Ring, 25 mm
152 Bearing, 6006
153 Bearing, 6005
183 Chuck Guard
184 Link Board for Wire
5327126 400 Hood Mounting Assembly
5327164 401 Hood Mounting Assembly Cover
5327165 402 Hood Mounting Assembly Bracket
5327166 403 Hood Rotating Shaft
5327167 404 Hood Shaft Bushing
5327168 405 Hood Spring
5327179 406 Snap Ring, 36 mm
