TROUBLESHOOTING
Water not being drawn in
• Check Ball Stuck
Shutoff seacock and remove intake hose
Using an eraser end of pencil be sure check ball is
moving freely
• Debris lodged in intake valve body
Check and clean valve body
• Piston O-ring worn
Replace Piston O-ring
• Inlet valve in wrong position
Inlet valve should only rotate 1/4 turn
Leak around piston sha
• Cartridge seal worn
Replace cartridge seal
Inspect and replace piston shaft if scored
Water accumulates in the bowl too fast
• Flapper valve not seated properly
Close intake valve and pump dry - clean or repalce
apper valve as necessary
• Joker valve not closing or opening properly
Clog or restriction in discharge line
Close intake valve and pump dry - clean or replace
joker valve as necessary
Not enough water to rinse bowl
• Intake valve positioned improperly
Be sure inlet knob only turns 1/4 see g. #3
• Debris around intake or discharge check balls
Remove check balls, clean and replace as necessary
• Scored pump housing or worn piston "O" ring
Inspect inside of housing replace "O" ring and
housing as necessary
• Intake line or strainer clogged
Clean line and strainer
Water rises in bowl
• Vented loop(s) not breaking siphon
Close discharge seacock, then intake seacock to
determine which is causing the problem. Clean or
replace vented loop(s) parts.
• Joker valve worn
Inspect, clean or replace as needed
Odor comes from head area when ushed
• Marine vegetation lodged in bowl
Remove bowl and attach pressure water at spud assy.
Install strainer in intake line
• Intake water is foul (most common in salt and brackish)
Install Knocks Out Odors Kit (KO2) to help deodorize
intake water
• Back pressure from holding tank
Tank full or vent clogged, inspect and clean
• Permeated discharge hose
rub with warm damp rag if smell transfers to rag
replace hose (Saniex (SFH) recommended).
RARITAN INSTALLATION ACCESSORIES
Part No. Description
163000 In-Line Strainer
164000BR Push button switch
1PCP22 C.P., Cleans Potties, Bio-enzymatic, 22 oz.
CHTII Compact holding tank - 5 gallon
SFH Sani-Flex Hose
SL1CC Super Lube 1cc tube
KO2 Knocks Out Odor Kit
TD90319 Vented Loop 3/4"
TD90323 Vented Loop 1 1/2"
TD90314W "Y" Valve
BOWL & SEAT
Part No. Description
16 1236AW Spud assy.
1 1237W Marine-size Bowl assy.
1 1244W White Household-style Bowl assy.
7 25105 Bowl Gasket
2 1238SC Marine-size seat & cover; Slow Close
2 1245SC Household-style seat & cover; Slow
Close
11 VCAP Vinyl Cap
OVERHAUL KITS
Part No. Description
PHRKIIC PHII&PHEII-Cartridge Seal
PHIIPUMP PHII Pump replacement assembly
ADDITIONAL PARTS FOR RARITAN PH SUPERFLUSH
L563 0316kgs
