V-09 05/2014 - 26 -
Option
Also for reducing the steam escape at the drain pipe an additional vent pipe can be fitted to the drain pipe. In
this extra vent pipe holes must be drilled where air is sucked in and condensates the steam. pic 1/2
1
8 mm
1/8"
2
Interfaces
a) Optional all CombiMaster® Plus can be retrofitted with an Ethernet interface
b) SelfCookingCenter® 5Senses are equipped with an Ethernet interface as a standard.
Show mode units (operator panel active, heating and fan motor are continuously o)
For converting units into show mode units a modification instruction is available at
RATIONAL
