Notes on using your unit
18 / 61
Max. load sizes for each unit size
6 x 1/1 GN 30 kg (max. 15 kg per rack)
6 x 2/1 GN 60 kg (max. 30 kg per rack)
10 x 1/1 GN 45 kg (max. 15 kg per rack)
10 x 2/1 GN 90 kg (max. 30 kg per rack)
20 x 1/1 GN 90 kg (max. 15 kg per rack)
20 x 2/1 GN 180 kg (max. 30 kg per rack)
Exceeding the maximum load size can lead to damage on the device.
Please note the specifications for maximum load sizes for food in the application manual.
Table-top units with hanging racks
(6 x 1/1 GN, 6 x 2/1 GN, 10 x 1/1 GN, 10 x 2/1 GN)
- To remove, raise the hanging rack slightly in the middle.
Pull it out of the front locking mechanism first, then
the lower mechanism and finally the upper locking
mechanism.
- Swivel the hanging rack to the middle of the cooking
cabinet.
- Release the hanging rack from its fixing by lifting it up.
Reverse the above sequence to reset.
