Rato 212cc - Engine Parts List and Descriptions

·
30
·
PARTS LIST AND DIAGRAM ASSEMBLY DIAGRAM
PART Description - EN QTY PART Description - EN QTY
1 GASKET, CYLINDER HEAD 1 50 BOLT, VALVE ADJUSTING 2
2
COVER SUBASSEMBLY, CYLINDER HEAD 1 51 ROCKER, VALVE 2
3 GASKET, CYLINDER HEAD COVER 1 52 NUT, VALVE ADJUSTING 2
4 TUBE, BREATHER 1 53 NUT, VALVE LOCK 2
5 BOLT 4 54 SPRING, VALVE 2
6 STUD 1 55 STARTER ASSY, RECOIL 1
7 STUD 1 56 BOLT 4
8 STUD 2 57 SHROUD 1
9 PIN 2 58 SHROUD, CYLINDER BODY 1
10 BOLT, CYLINDER HEAD 4 59 SHIELD,LOWER 1
11 PLUG, SPARK 1 60 PROTECTOR, OIL 1
12 HEAD SUBASSEMBLY, CYLINDER 1 61 SWITCH SUBASSEMBLY, STOP ENGINE 1
13 CRANKCASE SUBASSEMBLY. 1 62 BOLT 2
14 SENSOR, ENGINE OIL 1 63 BOLT 1
15 GEAR ASSY, GOVERNOR 1 64 COLLAR 1
16 ARM, GOVERNOR 1 65 BOLT 1
17 BOLT, DRAIN PLUG 2 66 BOLT 4
18 WASHER 2 67 CARBURETOR ASSY. 1
19 BEARING 1 68 GASKET, AIR CLEANER 1
20 SEAL, OIL 1 69 GASKET, CARBURETOR 1
21 WASHER 1 70 PLATE, CARBURETOR INSULATOR 1
22 PIN 1 71 GASKET, CARBURETOR INSULATOR 1
23 BOLT 2 72 NUT 2
24 COVER, CRANKCASE 1 73 CLEANER, AIR 1
25 BEARING 1 74 GASKET, EXHAUST OUTLET 1
26 SEAL, OIL 1 75 NUT 2
27 GASKET, CRANKCASE 1 76 MUFFLER ASSY 1
28 PIN 2 77 TANK, FUEL 1
29 DIPSTICK SUBASSEMBLY, OIL 1 78 STRAINER,FUEL 1
30 PLUG SUBASSEMBLY, ENGINE OIL 1 79 COVER, FUEL TANK 1
31 BOLT 6 80
OUTLET SUBASSEMBLY, FUEL TANK OIL 1
32 CRANKSHAFT ASSY. 1 81 CLAMP 2
33 CLIP, PISTON PIN 2 82 TUBE, FUEL 1
34 PISTON 1 83 BOLT 1
35 PIN, PISTON 1 84 NUT 2
Parts List
