Rato 212cc - Ordering Replacement Engine Parts

·
31
·
36 ROD, CONNECTING 1 85 NUT, FLYWHEEL 1
37 RING, THE FIRST 1 86 PULLEY,STARTER 1
38 RING, THE SECOND 1 87 IMPELLER 1
39 RING SET, OIL 1 88 FLYWHEEL SUBASSEMBLY 1
40 CAMSHAFT ASSY. 1 89 BOLT 2
41 VALVE, EXHAUST 1 90 COIL, IGNITION 1
42 VALVE, INTAKE 1 91 CONTROL ASSY, THROTTLE 1
43 SEAT, VALVE SPRING 1 92 BOLT 2
44 RETAINER,EXHAUST VALVE 1 93 SPRING, GOVERNOR 1
45 R0TATOR, VALVE 1 94 ROD, GOVERNEOR 1
46 GUIDE, SEAL 1 95 SPRING, THROTTLE VALVE RETURNING 1
47 TAPPET, VALVE 2 96 BOLT, GOVERNOR SUPPORT 1
48 LIFTER, VALVE 2 97 NUT 1
49 PLATE SUBASSEMBLY, LIFTER STOPPER 1 98 SUPPORT SUBASSEMBLY, GOVERNOR 1
ORDERING REPLACEMENT PARTS
Customer service toll-free number for ordering parts: 1-866-567-4089
When ordering parts, please be prepared to give the following
information:
•The product number: 060-7559-6
•The name of the product: RATO 212cc Gasoline Powered Engine
PARTS LIST AND DIAGRAM ASSEMBLY DIAGRAM
Power Take-Off Diagrams
