SERVICE MANUAL
RAVAGLIOLI S.p.A.
RAVTD5040WD / 5060WD / 5080WD
RAVTD5080WS - RAVTD1760WS/1780WS
RAVTD1850WS - RAVTD2200WS
Code R0184 - rev.1.2
(01/2011)
Page 6/22
Ravaglioli S.p.A. - Via I° Maggio, n° 3 (Frazione di Pontecchio Marconi)
40037 Sasso Marconi (Bologna - Italy)
Tel. 051/ 67.81.511 – Fax 051/ 84.64.67 e-mail: rav@ravaglioli.com
DEMO MODE: In a standard installation, in order to pass from NORMAL mode to DEMO
mode (and vice versa), press contemporaneously the keys Ctrl+D.
In a Demo installation it is possible to choose any model between all the range, initially
appears the above indicated page, select the model and press F4 to continue
Figure 9
1.2 Update
The update software of the RAV Wheel Aligners AS9 series, consists of some files
including a SETUP.EXE file.
To update the AS9 SW simply made a double click on SETUP.exe
If also DATA BANK updating is required, follow the procedure described in the User
manual, copying first the Database file from the USB flash disk to the PC and then
unlock it using the “Token import” procedure.
