TECHNICAL SPECIFICATIONS
TABLE 4. GNSS Sensor Specifications
TABLE 5. Horizontal Accuracy
TABLE 6. Communication Specifications
TABLE 7. Power Specifications
Item Specification
Receiver Type GNSS L1
Signals received GNSS and GLONASS
Channels 114
GNSS sensitivity -142 dBm
SBAS tracking 3-channel, parallel tracking
Update rate 10 Hz standard
Cold start < 60 s typical (no almanac or RTC)
Warm start < 30 s typical (almanac and RTC)
Hot start < 10 s typical (almanac, RTC, and position)
Maximum speed 1,850 kph (1,149 mph)
Maximum altitude 18,288 m (60,000 ft)
Item Specification
RMS (67%) 2DRMS (95%)
SBAS (WAAS) .3 m (11”) .6 m (23”)
Autonomous, no
corrections
1.2 m (47”) 2.4 m (94”)
Item Specification
Serial 2 full-duplex RS-232
Baud Rates 4800 - 115200
Data I/O protocol NMEA 0183
Item Specification
Input Voltage 7 - 32 VDC with reverse polarity operation
Power Consumption < 3.2 W nominal GNSS (L1/L2), GLONASS (L1/L2)
Current Consumption 0.26 nominal GNSS (L1/L2), GLONASS (L1/L2)
