3
FEEDBACK
500S™ INSTALLATION
DISPLAY, MOUNTING, AND CONNECTIONS
ADAPTER INSTALLATION
All connections and ports are located on the bottom of the unit (as shown below).
FIGURE 2. Bottom of 500S™
At Raven Industries, we strive to make your experience with our products
as rewarding as possible. One way to improve this experience is to provide
us with feedback on this manual. Your feedback will help shape the future
of our product documentation and the overall service we provide. We
appreciate the opportunity to see ourselves as our customers see us and
are eager to gather ideas on how we have been helping or how we can do
better. To serve you best, please send an email with the following
information to
techwriting@ravenind.com
-500S™ Smart Antenna Installation Guide
-Manual No. 016-0171-668 Rev. A
-Any comments or feedback (include chapter or page numbers if
applicable).
-Let us know how long have you been using this or other Raven products.
We will not share your email or any information you provide with anyone
else. Your feedback is valued and extremely important to us.
Mounting
Holes
Unit Label
Power and Signal
Status LED
