4
TABLE 1. Adapter Information
STATUS LED
The 500S™ uses a single LED (see Figure 2 on page 3) that provides system
information based on the LED color and status.
TABLE 2. Status LED
500S™ MOUNTING
This section provides information on 500S™ antenna mounting locations and
options.
SELECTING THE PROPER ANTENNA LOCATION
Proper antenna placement is critical to positioning accuracy.
To select the proper antenna location:
• Place the antenna with an unobstructed view of the sky. An obstructed view of the
sky may impair system performance.
• The GNSS engine computes a position based on measurement from each
satellite to the internal GSS receiver.
• Mount the antenna on or close to the center of your point of measurement.
• Ideal antenna placement on a vehicle is the center of the cab roof assuming
there is a clear view of the sky.
• If possible, keep other antennas at least 91 cm (3’) away from the 500S™ receiver.
• Position the antenna as high as possible.
Port/Connection Description
Mounting Holes
Four off-set mounting holes. Two adapters are
shipped with the antenna as a single mounting kit.
The first adapter includes a marine 1” standard,
adaptable to 5/8” for use with magnetic mount.
Color Status
Blinking Red The power is on
Blinking Amber GNSS position is available
Blinking Any Color The receiver is operational
Solid Color for Extended Period The receiver has malfunctioned
