4 Using the Product
The Raycus continuous fiber laser (with network port) has
stopped using the super terminal. After the laser is powered on, there
is no display on the super terminal. Please log in to the official website
of Raycus to download the new version of the upper computer
software and upper computer software instruction manual.
Web http://www.raycuslaser.com/index.php/index-show-tid-53.html
4.1 Front panel
Figure 4 shows the front panel style of Global Version 2000W CW laser:
Figure 4 Global Version 2000W laser front panel
4.2 Rear Panel
Figure 5 shows the rear panel style of Global Version 2000W CW laser:
Figure 5 Global Version 2000W laser real panel
