User’s guide Ytterbium Pulsed Fiber Laser RFL-P20QB～P30QB Ver.: 2.0
1
1. Description
1.1. Product description
Raycus P20QB/P30QB pulsed fiber laser is an ideal high power laser source with high speed
and high efficiency. It is specially designed for industrial laser making system and other
applications.
Compared with traditional lasers, pulsed laser has some unique advantages in increasing the
conversion efficiency of the pump light 10 times higher. Its low power consumption and
automotive design make it appropriate for operating both in and outside the lab. Besides, it is
exquisite and convenient for its independence in placement, free time in using and facility in
connecting to equipment directly.
The device can emit 1060~1085nm wavelength pulsed light under the control of industrial
laser’s standard interface driven by 24VDC power source.
1.2. Actual configuration list
Table 1. Configuration list
1.3. Environmental requirements and cautions
Pulsed laser should be driven by 24VDC±1V power source.
(1) Caution: Make sure the corresponding wires of the device are properly grounded.
(2) All the maintenance to the device should only be done by Raycus, because there is no
replacement or accessory provided with the device. Please do not try to damage the labels or
open the cover in order to prevent against electric shock, or the warranty will be invalid.
(3) The output head of the product is connected with an optical cable. Please be careful handling
the output head. Avoid dirt and any other contaminations. Please use the specialized lens
paper when cleaning the lens. Please lid the laser with protective cover of the light isolator to
be against dirt only when the laser is not installed in the device or not in working.
(4) If the operating the device fails to follow this instruction, the protective function will be
To Next Page
