Page #6 background imageLoading...
Page #6 background image
Users guide Ytterbium Pulsed Fiber Laser RFL-P10Q/P20Q/ P30Q/ P20QE/P50QB Ver.: 2.0
2 / 9
6) The device has three cooling fans at the rear panel to dissipate heat. In order to guarantee
enough airflow to help giving heat off, there must be a space of at least 10 cm’s width for
airflow in front and rear side of the device. As the cooling fans are working at blow condition,
if laser is mounted in a cabinet with fans, the direction should be same as lasers fans.
7) Do not look into the output head of the device directly. Please do wear appropriate laser
safety eyewear during the time when operating the device.
8) Make sure the pulse repetition rate higher than 20 kHz.
9) For the longest time without pulse is only 100 us. If there is no pulse output, please stop
marking at once, to avoid further damage of the device.
10) Power source sudden interruption will do great harm to the laser device. Please make sure
the power supply works continuously.
1.4. Specifications
Table 2. 10Q20QE20Q30Q50QB pulsed fiber laser specifications
Pulsed fiber laser
10Q 20QE
20Q
30Q 50QB
Wavelengthnm
1060~1085 1060~1085 1060~1085 1060~1085
1060~1085
Polarization
Random Random Random Random Random
Optical isolator
Yes Yes Yes Yes Yes
Nominal average output power (W)
10
20
20
30
50
Single pulse energy (mJ)
1@20kHZ 0.66@30kHZ 1@20kHZ 1@30kHZ 1@50kHz
Beam qualityM
2
<1.5 <1.5 <1.5 <1.5 <1.6
Beam Diametermm 68 68 68 68 68
Pulse durationns 80-100@20kHZ 115-140@30kHZ 90-130@20kHZ 90-130@30kHZ 90-150@50kHz
Pulse repetition ratekHz 20-60 30-60 20-60 30-60 50-100
Output Power Tunability%
10-100 10-100 10-100 10-100 10-100
Output Fiber Cable lengthm
2.0
2.0
2.0
2.0
2.0
Working voltageVDC 24±1 24±1 24±1 24±1 24±1
Power consumption
20
)(
W
120
170
170
240
340
Cooling
Forced Air Cooled
Forced Air Cooled
Forced Air Cooled
Forced Air Cooled
Forced Air Cooled
Dimension W×D×Hmm
260×391×120
260×391×120
260×391×120
260×391×120
260×391×120
Operating temperature 040 040 040 040 040
Store temperature -2060 -2060 -2060 -2060 -2060
humidity%
≤80 ≤80 ≤80 ≤80 ≤80
