Productdimensions
Axiom7trunnionmountdimensions
A
250 .4mm(9.86in)
B
162.5mm(6.4in)
C
76.4mm(3in)
D
•S traightconnectors=218mm(8.58in)
•Right-angledconnectors=198mm(7.79in)
Axiom7surfaceandflushmountdimensions
Usingadaptorbrack et
28
