Raymarine AXIOM XL 16 - Product Dimensions

Productdimensions
XL16XL19XL22XL24
A
394.9mm(15.55
in)
461.78mm(18.18
in)
533.56mm(21.00
in)
578.40mm(22.77
in)
B
248.22mm(9.77
in)
289.44mm(11.40
in)
326.33mm(12.85
in)
386.84mm(15.23
in)
C
9mm(0.35in)
D
Minimum:6mm(0.24in)
Maximum19mm(0.75in)
E
253mm(9.96in)294mm(11.57in)331mm(13.03in)392mm(15.43in)
F
73.96mm(2.91in)73.95mm(2.91in)79.75mm(3.14in)76.36mm(3.01in)
G
101mm(3.98in)
Note:
•DimensionDaboveshowstheminimumandmaximumthicknessofthemountingsurfacewhen
surfacemountingtheMFD.
•DimensionsC+Dshowstheminimumandmaximummountingsurfacethicknesswhenflush
mountingtheMFD.
Installation
21
