2xclass3orclass0devices
3xclass2devices
3xclass1devices
PoEconnections
Intheexampleabovethecombinationofthe3PoEdevicespowerrequirementsdoesnotexceed
thePoEavailablefromtheMFD.All3deviceswillbepoweredbytheMFD.
Important:
ThePoEdevicesshouldbeconnectedusingRayNetcables.
TheferritessuppliedwithyourMFDmustbeusedonallRayNetnetworkconnections.
ThepowersupplyattheMFDmustexceed9.5VdcforPoEtobeavailable.
Connections39
