3.10a9xanda12xpartssupplied
Thefollowingitemsaresuppliedwithyoura9xand
a12xvariantMFD.
D13066-1
x4
1
4
7
9
10
11
5 6
8
2 3
1Frontbezel
2
Multifunctiondisplay(MFD)
3Mountinggasket
4
Suncover
5
Trunnionbracketkit
6Documentationpack
7
SeaTalk
ng
toDeviceNetadaptorcable
8
4xNuts,bolts,springwashersandwashers(can
beusedforeithersurfaceorbracketmounting.)
9
3m(9.8ft.)SeaTalk
ng
spurcable
10
2m(6.6ft.)RayNetcable
11
1.5m(4.9ft.)Poweranddatacable
(Power/NMEA/Video)
3.11e7/e7DPartssupplied
Thepartsshownbelowaresuppliedwiththee7/
e7Dmultifunctiondisplay.
D12170-4
x4
x4
x4
1
2
8
3
4
5
7
9
6
1.Suncover.
2.Frontbezel.
3.Multifunctiondisplay.
4.Rearbezel(requiredfortrunnionbracket
mounting).
5.Gasket(requiredforushmounting).
6.Screwpack,includes:
•4xrearbezelxingscrews.
•4xsetsofxings(forsurfacemounting).
•4xsetsofxings(fortrunnionbracket
mounting).
7.Documentationpack,includes:
•MultilingualCD.
•Mountingandgettingstartedmultilingualguide
•Mountingtemplate.
•Warrantypolicy
8.Poweranddatacable.
9.Trunnionbracketkit.
44
