Raymarine gS Series Installation Instructions

4.13Sonarmoduleconnection
Externalsonarmodulescanbeconnecteddirectlyto
thedisplay’snetworkconnectionorcanbeconnected
totheSeaTalk
hs
network,viaaRaymarine
®
network
switch.
2connectionsarerequired:
•Networkconnection—transmitsthesonardata
toacompatibleRaymarine
®
MFD.
•Transducerconnection—Internalandexternal
sonarmodulesrequireconnectiontoacompatible
transducer.Internal600WandinternalCHIRP
DownVision
TM
sonarvariantdisplaysfeaturea
built-inmodule,enablingacompatibletransducer
tobeconnecteddirectlytothedisplay.
Networkconnection
Multiplesonarmodulescanbeconnectedtothe
samenetwork.
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNet
D12975-2
2
4
3
5
3
3
1
1.MFD
2.Raymarine
®
networkswitch
3.RayNetnetworkcables
4.Sonarmodule1(e.g.CHIRPsonarmodule)
5.Sonarmodule2(e.g.CHIRPDownVision
TM
sonarmodule)
Importantsoftwarerequirementsformultiple
sonarsystems
Ifyoursystemincludesmorethanonesourceof
sonardatayoumustensurethatanyCP300or
CP450Csonarmodulesarerunningsoftwareversion
v4.04orlater.
Thisappliestosystemswhichinclude:
•AnynumberofMFD(s)withaninternalsonar
moduleplusaCP300and/orCP450Csonar
module;or
•NoMFD(s)withaninternalsonarmodule,but
morethanoneCP300orCP450Csonarmodule.
ThisdoesNOTapplytoanysystemsthatdoNOT
includeaCP300orCP450Csonarmodule.
Note:Forsoftwaredownloadsandinstructions
onhowtoupdatethesoftwareforyourproduct(s),
visitwww.raymarine.com/software.
