Description
Qty. Symbol Part No.
Capacitors (cont.)
Elec., 10 µF/16WV 5 C 1 , 5, 6, 7, 8
Elec., 47 µF/25WV 4 C47, 49, 50, 55
Elec., 1000 µF/25WV 1 C52
Coils
Coil, 5- 1 9-CZ99Z 1 CH1
Resistors
Metal Film, 4.7 ohm (3W) 1 R16
Metal Glaze, 100 ohm 3 R37, 42, 45
Metal Glaze, 1k ohm 6 R1, 3, 5, 7, 9,46
Metal Glaze, 2.2k ohm 1 R11
Metal Glaze, 10k ohm 8 R2, 4, 6, 8, 10, 12, 47, 48
Metal Glaze, 22k ohm 1 R13
Semiconductors
I.C., TD62307P 1 IC9
I.C., TLP121-4 1 IC10
I.C., TLP121-1 2 IC11, 13
Regulator, TA78006AP 1 IC7
Regulator, TA78008AP 1 IC8
Transistor, 2SA1298(O) 1 Q1
Transistor, 2SC41 16(O) 1 Q2
Diode, lSl888A 7 D1, 2, 3, 4, 5, 6, 9
Diode, 1N5401 1 D15
Miscellaneous
Relay, G6E-134P (12V DC) 5 RY1, 2, 3, 4, 7 G263648-14
Relay, G6B-2114P (12V DC) 2 RY5, 6 G263648-15
Connector, 2-173145-8 1 CN2
Connector, 5483-02 1 CN4
Connector. 5483-04 1 CN3
6—3
