Description
Miscellaneous (cont.)
Connector, 5483-05
Qty.
1
Symbol
CN5
Part No.
Connector, 965 1S-6A 1 CN7
Connector 965 1S-20A 1 CN6
*****AGC PCB ASSEMBLY SECTION*****
AGC PCB Assembly 1 G263648-3
Capacitors
Elec., 10~F/16WV 2 C30l, 302
Resistors
Metal Glaze, 4.7k ohm 4
302, 303, 304,
305
Metal Glaze, 10k ohm 2 R306, 307
Metal Glaze, 22k ohm 1 R30 1
Semiconductors
Transistor, 2SC27 1 2
(GRTE8SL)
2 Q302, 303 G263597-9
Transistor, RN1403 1 Q304
Transistor, RN1410 1 Q301
Diode, 1SS308 1 D30l
Diode, 155193 1 D302
Diode, 1 SS 1 23 1 D303
Zener Diode, 02CZ6.2X 1 D304
Miscellaneous
Connector, B5B-PH-K-S , 1 CN301
Connector, B7B-PH-K-S 1 CN302
6—4
To Next Page
