*****CPU PCB ASSEMBLY SECTION*****
Description
Qty. Symbol Part No.
CPU PCB Assembly 1 G263648-4
Capacitors
Ceramic, 10 pF (NP0) 2 C201 , 202
Ceramic, 100 pF (NP0) 20 C207, 208, 209, 210, 211,
212, 213, 214, 215, 216, 217,
218, 219, 220, 221, 222, 223,
224, 225, 245
Ceramic, 0.1 µF 6 C203, 228, 232, 237, 238, 241
Elec., 1 µF/1 6WV 2 C226, 227
Elec., 4.7 µF/16WV 1 C236
Elec., 10 µF/25WV 1 C244
Elec., 100 µF/10WV 1 C205
Elec., 100 µF/16WV 1 C231
Elec., 100 µF/25WV 1 C206
Mylar, 0.0082 µF 1 C229
Tant., 1 µF/25WV 1 C230
Transformers
EL Transformer, S19-C99SPT 1 T201
Resistors
Metal Glaze, 0 ohm (Jumper) 1 R245
Metal Glaze, 10 ohm 1 R247
Metal Glaze, 22 ohm 1 R250
Metal Glaze, 100 ohm 7 R237, 238, 239, 240, 241,
242, 247
Metal Glaze, 150 ohm 1 R249
Metal Glaze, 220 ohm 1 R268
Metal Glaze, 1k ohm 21 R218, 219, 220, 221, 222,
223, 224, 225, 226, 227,
228, 229, 230, 231, 232,
6—5
